• Pole-Position：Momentary Type,SPST
• Contact Rating：12VDC,50mA
• Contact Resistance：500mΩmax，5VDC;1A,
by Method of Voltage DROP
• Insulation Resistance：100MΩ min.100VDC for 1 minute
• Dielectric Strength：Breakdown is not Allowable;
250 VAC for 1 Minute
• Operating Force：200±80gf；450±150gf
• Operating Temperature Range：-20℃ ~70℃
• Operating Life：100,000 cycles
• Total Travel：0.20±0.10mm
|
 |
   |
| Part Number | Contact Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Operating Temperature | Operating Life | Total Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|
| R2998L-M-2-B-V | 12VDC,50mA | 500mΩmax，5VDC;1A,by Method of Voltage DROP | 100MΩ min.100VDC for 1 minute | Breakdown is not Allowable;250 VAC for 1 Minute | 200±80gf；450±150gf | -20℃ ~70℃ | 100,000 cycles | 0.20±0.10mm | 暫無 |
| R2998L-H-2-Y-V | 12VDC,50mA | 500mΩmax，5VDC;1A,by Method of Voltage DROP | 100MΩ min.100VDC for 1 minute | Breakdown is not Allowable;250 VAC for 1 Minute | 200±80gf；450±150gf | -20℃ ~70℃ | 100,000 cycles | 0.20±0.10mm | 暫無 |
| R2998L-AM-2-Y-V | 12VDC,50mA | 500mΩmax，5VDC;1A,by Method of Voltage DROP | 100MΩ min.100VDC for 1 minute | Breakdown is not Allowable;250 VAC for 1 Minute | 200±80gf；450±150gf | -20℃ ~70℃ | 100,000 cycles | 0.20±0.10mm | 暫無 |
| R2998L-M-2-Y-V | 12VDC,50mA | 500mΩmax，5VDC;1A,by Method of Voltage DROP | 100MΩ min.100VDC for 1 minute | Breakdown is not Allowable;250 VAC for 1 Minute | 200±80gf；450±150gf | -20℃ ~70℃ | 100,000 cycles | 0.20±0.10mm | 暫無 |
