• Pole-Position：OFF-<0N> for Momentary Type,SPST
• Contact Rating：100mA 12VDC
• Contact Resistance：200mΩ max
• Insulation Resistance：100MΩ min.500VDC
• Dielectric Strength：Breakdown is not Allowable;500 VAC for 1 Minute
• Operating Force：250±100gf
• Operating Life：1，000,000 cycles
• Operating Temperature Range：-10℃ ~ +60℃
• Total Travel：3.3±0.20mm
|
 |
   |
| Part Number | Pole-Position | Contact Rating | Contact Resistance | Insulation Resistance | Dielectric Strength | Operating Force | Operating Life | Operating Temperature | Total Travel | PDF下載 |
|---|---|---|---|---|---|---|---|---|---|---|
| RS998-N11AK | OFF-<0N> for Momentary Type,SPST | 100mA 12VDC | 200mΩ max | 100MΩ min.500VDC | Breakdown is not Allowable;500 VAC for 1 Minute | 250±100gf | 1，000,000 cycles | -10℃ ~ +60℃ | 3.3±0.20mm | 暫無 |
